Technical Data; Accessories; Declaration Of Conformity; Safety Considerations - Wolff Compactclean Betriebsanleitung

Includes:
Cleaner COMPACTCLEAN
Fine dust filter
suction hose
floor suction nozzle, suction pipepe
operating instructions

Accessories:

Flat nozzle
Adapter 50/38 mm
Micro filter,
When using electric machines, basic safety precuations
should always be followed to reduce the risk of fire,
electric shock and personal injury, including the
following:
Kompaktsauger COMPACTCLEAN, Artikel-Nr. 038909,
Downloaded from www.Manualslib.com
Item no. 042583
Item no. 038921
Item no. 038922
Vacuum producer
capacity
03/2006Fugenfräse FRÄSMASTER
manuals search engine

1.0 Technical Data

HxWxL . . . . . . . . . . . . . . . . . . . . . . . . . . . . .740x380x380 mm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 kg
Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .f 50 mm
Hose length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 m
Collecting sack, container . . . . . . . . . . . . . . .560x700 mm/20 l
Flow, max . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190 m
Neg. pressure, . . . . . . . . . . . . . . . . . . . . . . . . . . . .max 24 kPa
Power consumption . . . . . . . . . . . . . . . . . .1400 W, 220V/110V
Fine filter polyester, . . . . . . . . . . . . . . . . . . . . . . . .area 1.5 m
Degree of separation (DIN 24184/3) . . . . . . . . . . . . . . .99,9 %
Filter area, microfilter . . . . . . . . . . . . . . . . . . . . . . . . . .0.85 m
Degree of separation, microfilter (EN) . . . . . . . . . .> 99,995 %
Sound level . . . . . . . .< 70 dB(A) 0 50 100 150 200 m3/h kPa
Autostart von 200W - max. 1200W
2.0

DECLARATION OF CONFORMITY

We declare our sole responsibility that this product is in
conformity with standards or standardized documents in
accordance with following Directives; 2006/42/EC, AFS
1994:48, AFS 1992:2 ASBEST and EN 60204-1
Serial Number and manufacturing year are indicated in a rating
plate on the machine. For separation of endangering dust as
asbestos the machine must be equipped with microfilter.
If any changes will be done, without our permission or if not
using original filter, the above responsibility is not valid.
06
Dipl.-Ing. (FH) Dieter Hammel
Konstruktionsleitung
i.V.
WOLFF | Eine Marke der Uzin Utz Gruppe | D-71665 Vaihingen/Enz | Dieselstraße 19

3.0 Safety Considerations

Read all instructions before attempting to operate this machine
and save these instructions.
If not this safety consideration follows the guarantee is not valid
and personal injury and machine damage can be caused.
/h
3
2
2
10
