Controls and Indicators

C
ONTROLS AND
1 Drive (Hi Speed)
2. Drive (Low Speed)
3. Level
4. Horn Button
5. Lift/Lower Button
6. Glow Plug
7. Engine Start
8. Emergency Stop Button
9. Display
10. Joystick
1. Emergency Stop
2. Elevate
3. Descend
4. Enable
5. Glow Plug
6. Start
Operation Manual
I
NDICATORS
8
7
3
2
1
1
2
Platform Controls
4
5
Chassis Controls
3 4
Figure 2: Controls and Indicators
10
6
9
6
5
