Instar IN-7011 HD Bedienungsanleitung Seite 23

01 - Antenna Connector
02 - MicroSD Card Slot
03 - Infrared LEDs
04 - Lens
05 - Photosensor
06 - Audio output
07 - Alarm input
08 - Alarm output
09 - Audio input
10 - WPS / Reset
11 - Power Connector
12 - Network Port
13 - Camera Label
4.3. Status LEDs
Status LED
Constant on
Slow Flashing
Fast Flashing
Off
Go to http://install.instar.com
SMA connector (incl. 5dB antenna / not for PoE version)
Slot for MicroSD/SDHC cards (max. 32GB - 8GB included)
(built-in insde the camera PCB boards)
22 IR LEDs (nightvision @ 850nm)
6mm CS-Mount lens with a ~60º diagonal field of view
Twilight switch for IR LEDs
Chinch-connector for optional active loudspeakers
Input for potential free external alarm sensors
Output (relay) can support max. 24V/1A
Chinch-connector for optional active speakers
3 seconds for quick WiFi setup / 15-20 seconds for reset
12V / 2A DC - Plug Ø : 2,1mm (in) / 5.5mm (out)
RJ45 LAN-port / connector for Cat5e LAN cable or higher
Please refer to below 4.3 for Status LEDs
P2P ID, LAN MAC address and serial number (located at the
back of the wall mount)
Green LED
-
-
Data transfer through LAN
No network cable connected
or in WiFi mode
Orange LED
Network cable is connected or
in WiFi mode
-
-
Network cable is not connected
correctly
6-EN
