11 Technical Data

Display Unit
Sensor
Installed position
Flow range
Flow deviation
Operating pressure
Pressure loss up to 700 l/h flow
Water intake temperature drinking water
Water intake temperature not drinking water
Ambient temperature operation/storage/transport
Battery
Degree of protection Display Unit (only when wall-mounted) IPX 4
Degree of protection Sensor
Cable length
Inlet connection
Outlet connection
62 mm/50 mm/17 mm (L/W/H)
81 mm/43 mm/46 mm (L/W/H)
horizontal + vertical
100 – 700 l/h
+/– max. 5 %
max. 8 bar
< 0.2 bar
4°C to 30°C (in accordance with LFGB)
4°C to 60°C
0°C to 60°C
button cell 3VDC, Type CR2032
IPX 8
max. 1.5 m
1 x G 3/4" with installed O-Ring seal
1 x G 3/4" union nut
