Note – Connection impaired
After the headset and terminal device have been paired, a
connection is established automatically. If the Bluetooth
connection is not established automatically, check the
following:
• Check the Bluetooth settings of your terminal device to see
®
whether Hama BTH TOUCH is connected. If not, repeat the
steps listed under 5.1. Bluetooth
• Check whether obstacles are impairing the range. If so,
move the devices closer together.
• The performance can also be affected by a weak battery.
6.3. Bluetooth multipoint connection
®
This headset can be connected with two Bluetooth
terminal devices simultaneously.
• First connect the headset with the first terminal device as described in 5.1.
• Then disable Bluetooth on that terminal device.
®
• Next, connect the headset with the second terminal device as
described in 5.1.
• Activate Bluetooth on the first terminal device once more. The
®
headset now connects to that terminal device automatically.

6.4. Audio playback

Note
• Note that the functions described under 5.4. and 5.5. are
only possible with an active Bluetooth
• Your terminal device must also support the individual
functions.
• For more information, please refer to the operating
instructions of your terminal device.
• Functions can still be controlled directly via the terminal device.
• Set the volume on your terminal device to a low level.
• Switch the headset on using the MFB button (2). Upon
successful connection, a voice says, "PAIRED".
• Start audio playback on the connected terminal device.
• Swipe upwards on the touch control panel (1.a) to increase
the volume.
• Swipe downwards on the touch control panel (1.b) to reduce
the volume.
• Press the MFB button (2) to start or pause audio playback.
• Swipe forwards on the touch control panel (1.c) to go to
the next track.
• Swipe backwards on the touch control panel (1.d) to go to
the previous track.
4
®
pairing.
®
-enabled
®
connection.
®

6.5. Hands-free function

• Press the MFB button (2) once to answer an incoming call.
• Press the MFB button(2) twice or use your telephone to reject an
incoming call.
• During a call, press the MFB button (2) once to end the call.
• Press the MFB button (2) twice to call the number of the last call.
Note – Call quality
To increase the call quality, make sure that you are near the
headset with your mobile phone during the call.
6.6. Audio input socket
In addition to connecting this headset via Bluetooth
connect it using the included AUX cable.
To do so, insert one end of the cable into the terminal device and
the other end into the audio input socket (3) on the left side of
your headset.
6.7. Disconnecting the headset
• Switch the headset off.
• Disconnect the headset via the Bluetooth
terminal device.

7. Care and Maintenance

Only clean this product with a slightly damp, lint-free cloth and do
not use aggressive cleaning agents. Make sure that water does not
get into the product.

8. Warranty Disclaimer

Hama GmbH & Co KG assumes no liability and provides no
warranty for damage resulting from improper installation/mounting,
improper use of the product or from failure to observe the operating
instructions and/or safety notes.
9. Service and Support
Please contact Hama Product Consulting if you have any questions
about this product.
Hotline: +49 9091 502-115 (German/English)
Further support information can be found here:
www.hama.com
, you can
®
settings on your
®
