S M A R T C U B E
Installation
The SMARTCUBE is mounted directly on the wall or with the installa-
tion frame in an in-wall back box. It can also be used with the base as a
freestanding device.
Mounting on the base
On-wall installation
Mounting plate with (1) mounting holes and (2) opening for charging cable
30
Position the bottom edge of the SMARTCUBE in
the base and click it in. The SMARTCUBE is held
by a magnet and can therefore be used in an
upright and in a horizontal position. At the back
of the base there is a flap for the charging cable.
Screw the mounting plate supplied onto the wall
and click in the SMARTCUBE as described above.
