System Overview

EXPLANATION OF LED DISPLAYS

Fig. 10
Symbol
Table 1
68
Meaning
Lights when the wireless LAN properties are
activated.
Lights when the computer is switched on.
Flashes when the battery reaches a low charge
condition.
Lights when the computer is in power saving
mode
Hard disk or CD-ROM drive is being accessed.
Lights when the battery is charging.
Lights when Caps Lock is on.
Lights when Num Lock is on.
(1) Wireless LAN
(2) Power
(3) Standby
(4) Drive access
(5) Battery
(6) Caps Lock
(7) Num Lock
