SUGGESTED EMBEDDING DIMENSIONS
Fig.02
Fig.04
Item no.
FIRECOOL
COMPACT
Item no.
FIRECOOL
COMPACT
18
L
350mm 330mm
A ( L1<A<L) B ( W1<B<W )
Suggested size
340mm 170mm
Fig.03
L1 W
180mm
C
Minimum size
135mm
W1
160mm
