GB

4. Technical data

Cutter rail length
Cutting length
Tooth spacing
Cutting thickness max.
Cuts/min
Charging time
Sound pressure level, L
Sound power level, L
WA
K uncertainty
Vibration a
hv
K uncertainty
Weight
Battery pack
Voltage
Capacity
Battery charger
Mains voltage
Output voltage/current
The machine may exceed 85 dB (A). The operator
will require noise protection measures if this is the
case. The noise was measured in accordance with
EN 60745-1. The value of the vibrations emitted by
the handle was determined in accordance with
EN 60745-1.
Important.
The vibration value changes according to the area of
application of the electric equipment and may exceed
the specified value in exceptional circumstances.
Reduce noise generation and vibration to a
minimum!
Use only equipment that is in perfect condition.
Maintain and clean the equipment regularly.
Adapt your way of working to the equipment.
Do not overload the equipment.
Have the equipment checked if necessary.
Switch off the equipment when not in use.
Wear gloves.
14
520 mm
460 mm
64.8 dB
pA
84.8 dB
≤ 2.5 m/s²
18 V d. c.
230 V ~ 50 Hz
21 V d. c. / 3 A

5. Before starting

5.1 Installing the battery (Fig. 4)
Press the side pushlock buttons of the battery pack
as shown in Fig. 4 and push the battery pack into the
15 mm
mount provided. When the battery pack is positioned
as in Fig. 1, make sure that the pushlock buttons
11 mm
latch in place! To remove the battery pack, proceed
2200
in reverse order.
0.5 h
5.2 Charging the battery (Fig. 5)
1. Take the battery pack out of the equipment. Do
this by pressing the side pushlock buttons.
3 dB
2. Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Insert the power plug of the charger (5)
1,5 dB
into the mains socket outlet. The green LED will
2.0 kg
then begin to fl ash.
3. Insert the battery pack (6) into the battery
charger (5).
4. In section „Charger indicator" you will find a table
with an explanation of the LED indicator on the
1,5 Ah
charger.
The battery pack can become a little warm during the
charging. This is normal. If the battery pack fails to
charge, check:
whether there is voltage at the socket outlet
whether there is good contact at the charging
contacts
If the battery pack still fails to charge, send
the charging unit
and the battery pack
to our customer service center.
To ensure that the battery pack provides long ser-
vice, you should take care to recharge it promptly.
You must recharge the battery pack when you notice
that the power of the cordless grass trim-mer drops.
Never fully discharge the battery pack. This will
cause it to develop a defect.

6. Operation

Switching ON/OFF.
The hedge trimmer is equipped with a two-handed
safety switch. The machine works only when the
switch on the steady grip (Figure 1 / Item 3) is
pressed with one hand and the switch on the handle
(Figure 1 / Item 4) is pressed with the other hand. If
either switch is released, the cutters will stop moving.
Please watch out for the cutters as they slow down to
a standstill.
