JLPT1: Parallel Port Connector

This connector allows you to connect the optional parallel port with bracket.

EZ Debug LED

These LEDs indicate the debug status of the motherboard.
24
Overview of Components
2
1
1 RSTB# 2
4 ERR# 5
7 PRND2 8
10 Ground 11
13 PRND5 14
16 Ground 17
19 ACK# 20
22 Ground 23
25 SLCT 26
CPU - indicates CPU is not detected or fail.
DRAM - indicates DRAM is not detected or fail.
VGA - indicates GPU is not detected or fail.
BOOT - indicates the booting device is not detected
or fail.
26
25
AFD# 3
PRND1 6
LPT_SLIN# 9
PRND4 12
Ground 15
PRND7 18
Ground 21
PE 24
No Pin
PRND0
PINIT#
PRND3
Ground
PRND6
Ground
BUSY
Ground
