| ENGLISH
14. Remove the mounting aid and secure the outdoor station with your
hand to prevent it from falling out. A second person can be helpful.
15. Insert the microphone cable back into the board and replace the
front cover onto the outdoor station. Please ensure you do not crush
the microphone cable.
16. Screw the front cover on with the 4 Torx screws supplied for this
purpose. Please ensure that you do not tip or overtighten the
screws. The maximum tightening torque is 1.2 Nm. This value may
not be exceeded or the thread inserts on the flush mounting shell
can become unusable or tear out.
Note: self-adhesive foam is included to seal the front plate. This is
adhered on the edge of the front plate from the back.
ASSEMBLY OF THE INDOOR STATION
You can select the mounting height for the indoor station according to
your circumstances.
1. The casing on the indoor station is screwed together with two
GB
screws (B.17) and is kept together with projections and notches. To
separate the back section from the front section remove both screws
and the back section can then be simply removed.
2. Use the back section of the casing as an aid to draw the drill holes.
Make sure that you place the back section in a straight line.
3. Drill the mounting holes with a 6 mm drill and insert one dowel into
each hole.
4. Feed the wires through the correct insertion hole in the back section
of the casing and screw this.
5. Connect the wires in accordance with the wiring plan and place the
front casing section on the back casing section. Make sure that it
clicks into place correctly.
6. Screw the casing back together with the two screws (B.17).
SETTINGS ON THE INDOOR AND OUTDOOR STATIONS
ENCODING (Indoor station)
There are DIP switches (B.16) on the indoor station for encoding. Each
indoor station needs to be set to the correct code. If one party has
several indoor stations then the encoding must be the same for all
indoor stations belonging to the party.
One-family version
DIP switch 1 „ON", all others „OFF"
2-family version
Indoor station(s) for family 1
DIP switch 1 „ON", all others „OFF"
Indoor station(s) for family 2
DIP switch 2 „ON", all others „OFF"
NOTE: If two or more indoor stations are connected then DIP switch 6
must be switched to "ON" on the last indoor station.
CONVERSATION VOLUME (outdoor station)
The conversation volume on the outdoor station is set using the
potentiometer (A.9). For full volume turn the potentiometer carefully in
a clockwise direction to its limit and then turn it back a little. Turn it in
an anti-clockwise direction to reduce the volume.
CONVERSATION VOLUME (indoor station)
You can set the conversation volume on the indoor station in several
stages using the two buttons B.12 and B.13 on the side.
RINGER VOLUME (indoor station)
The ringer volume on the indoor station is set using the potentiometer
(B.15). For full volume turn the potentiometer carefully in a clockwise
direction to its limit and then turn it back a little. Turn it in an anti-
clockwise direction to reduce the volume.
CHANGING THE RING TONE (indoor station)
The ring tone can be changed using button B.11. Press the talk button
(B.6) to activate the indoor station. Then press on the melody button
(B.11) and a melody will play. Keep pressing the melody button until the
desired ring tone plays. To confirm the melody press the talk button. The
set melody is then saved.
If the system is disconnected from the mains the melody will be set back
to the factory setting.
DEACTIVATING THE RINGER MELODY (e.g. during the night)
It is possible to deactivate the ringer melody, e.g. in order not to be
disturbed at night. To do this, press the mute button (B.3) on the indoor
unit down once, briefly. The LED on the mute button lights up red to
remind you that the melody is deactivated. To re-activate the melody
press the mute button briefly again. The red LED will go out and the
melody is reactivated.
The optical signal (the illuminated frame on the talk and door opener
button) remains active even when the ringer melody is deactivated and
continues to light up when the bell is rung. The red LED also flashes if
the bell is rung while muted.
