5.6 Power display

Battery power fi ve-segment display, when the battery is
fully charged when the fi ve frame lights are on, when the
battery is undervoltage battery outside the frame fl ashes,
prompting the need to charge immediately.
Full power Four cells Three cells
display power display power display
Battery undervoltage
blinking
Fig.

5.7 Error Code Display

When the electric control system of the electric vehicle is
faulty, the meter will automatically display the error code,
refer to Exhibit 1 for the detailed defi nition of the error code.
Fig.
When an error code appears on the display interface,
!
please troubleshoot the problem in time, the electric car
will not be able to drive normally after the problem occurs.
Two cells One cell
power display power display
5.6
5.7
Part6 Personalized parameter
settings
Each setting item needs to be carried out when the vehicle is
!
stationary.
The operation steps of personalized parameter setting are as
follows:
In the power-on state, when the instrument shows speed as 0.
6. Personalized parameter settings
(1)Press and hold [ ]at the same time for more than 2
seconds to enter the personalized parameter setting item
selection interface;
(2)Short press [ ] to switch the interface of personalized
parameter setting item selection.
(3)Short press [ ]/[ ] for parameter selection, long
press [ ] for continuous plus operation, long press [
continuous minus operation.
(4)Short press [ ] to save the parameter setting and
return to the personalized parameter setting item selection
interface.
(5) Long press [ ] to save the parameter setting and exit
the personalized parameter setting item selection interface.
The personalized parameter setting item selection interface
has the following options:
] for
