Dispose of used batteries in a designated place

3. ECMA

VNT electronics s.r.o. is an active member of the ECMA
(Electronic Collar Manufacture Association), which represents
the highest quality manufacturers of electronic training aids for
dogs. The aim of all members of the association is to develop
and produce quality and reliable training systems that respect the safety of the
animal. For more information visit www.dogtrace.com or www.ecma.eu.com.

4. DEVICE DESCRIPTION

1. Target (half round red indicator) for magnet attachment (on/off)
2. Stainless steel contact points (plastic on vibration models)
3. Indication lights
4. Battery compartment cover
5. Belt
6. Test discharge lamp

5. RECEIVER PREPARATION

5.1 Inserting (replacing) the battery in the receiver

1. Use a Phillips screwdriver to remove the 4 screws on the receiver and remove
the cap from the top.
2. Insert a CR2 3V lithium battery in the correct polarity (as shown in Figure 2
on page 2).
3. Check that the rubber seal is seated correctly in the receiver cap (in the
receiver groove on the d-control mini). If there is dirt on the rubber seal,
clean it.
4. Replace the receiver cap and screw in all 4 screws with reasonable force.
22
(fig. 1 on page 2)
