1 Operating Elements and Connections

1.1 Monitor
1 Volume control
2 Indicating LEDs for the four camera channels:
C1 = reception channel 1
C2 = reception channel 5
C3 = reception channel 3
C4 = cable-connected camera, connected
to the jack C4 (16)
3 DIP switch on the lower side of the unit for defining
the number of the cameras used
(see chapter 4.2)
4 Button SKIP for manual selection of the camera
channels
5 Button for adjusting the operating mode
button not pressed ("AUTO"):
automatic camera selection
button pressed ("MANUAL"):
manual camera selection via the button SKIP (4)
6 POWER switch
7 Control TIME for adjusting the dwell time (2 – 60 s)
for a camera picture in the automatic selection
mode
8 Reception antenna (must not be broken off or
scratched)
9 Audio input (white phono jack) and video input
(yellow phono jack) for video recorder replay:
connection to the audio and video output of a
recorder
10 Audio output (white phono jack) and video output
(yellow phono jack) for video recorder replay or for
connecting a second monitor: connection to the
audio and video input of a recorder or a second
monitor
11 Selector switch for the signal source
CAMERA: The monitor is set to replay of the
camera signals.
VCR: The monitor is set to video recorder
replay.
12 Control V-HOLD for vertical synchronization
13 Brightness control BRT.
14 Contrast control CONT.
15 Low voltage jack DC IN for connecting the sup-
plied power supply unit
16 Connection jack C4 for operating a cable-connect-
ed camera, e. g. MONACOR TVCCD-510
10
1.2 Camera
17 Low voltage inline jack for power supply with
12 V /250 mA;
centre contact = positive pole;
required low voltage plug 5.5/2.5 mm
(outside/inside diameter)
18 Microphone
19 Lens
20 Transmitting antenna

2 Safety Notes

The units (monitor, camera, and power supply unit)
correspond to the directive for electromagnetic com-
patibility 89/336/EEC. The power supply unit also
corresponds to the low voltage directive 73/23/EEC.
Attention! The power supply unit and the monitor
are supplied with very high voltage dan-
gerous to life. Leave servicing to skilled
personnel only. Inexpert handling may
cause an electric shock hazard. Further-
more, any guarantee claim will expire if
the monitor, the power supply unit, or the
camera has been opened.
Please observe the following items in any case:
Caution! The picture tube of the monitor is
vacuous. In case of mechanical damage, there is an
implosion hazard and scattered glass may cause
injuries.
The units are suitable for indoor use only. Protect
them against dripping water and splash water, high
air humidity, and extreme temperatures (admissible
ambient temperature range -10 °C to +55 °C).
Do not place any vessel filled with liquid on the unit,
e. g. a drinking glass.
The heat generated within the units must be carried
off by air circulation. Therefore, never cover the air
vents.
Do not insert anything into the air vents! This may
result in an electric shock or in damage to the unit.
Do not operate the monitor or immediately dis-
connect the power supply unit from the mains
socket
1. if there is visible damage to the monitor, the
power supply unit, or the mains cable,
2. if a defect might have occurred after a unit was
dropped or suffered a similar accident,
3. if malfunctions occur.
In any case the units must be repaired by skilled
personnel.
A damaged mains cable of the power supply unit
must be replaced by the manufacturer or author-
ized skilled personnel only.
Never pull the mains cable when disconnecting the
mains plug from the socket, always seize the plug!
For cleaning only use a dry, soft cloth; never use
chemicals or water.
