EN
5 CCT / MTB button (color temperature adjustment and multi-function adjustment
button): In CCT mode, single click can quickly switch the color temperature
adjustment / Green&magenta adjustment cursor. Turn the knob clockwise /
counterclockwise to increase / decrease the color temperature value, or adjust the
green&magenta offset by ± 10 levels. In HSI mode, single click can quickly switch
the hue / saturation adjustment cursor. Turn the knob clockwise / counterclockwise
to increase / decrease the hue / saturation value. The same applies to RGBCW and
color paper modes.
In FX mode, clicking the CCT/ FRQ knob
【5.1】
switches the cursor from color temperature
adjustment to frequency adjustment. The
screen display will change as follows.
In FX mode, rotating the knob clockwise / counter-clockwise adjusts the color
【5.2】
temperature / frequency corresponding to the cursor area..
6 USB-C Power Supply and DMX Interface: You can connect a USB-C power source
such as a 140W PD charger, battery grip, 100W PD power bank, etc., to provide a
mobile power supply solution for the RC 100C, Max 110W DC input.. Additionally,
you can connect a USB-C to DMX adapter to establish a wired DMX connection
for the RC 100C.
7 Mini XLR Input Interface: You can connect an AC to DC adapter (optional) via this
port to provide continuous wall plug power supply for the RC 100C.
10
8 V-Mount Lock: Provides V-Mount battery and NP-F battery plate mounting options.
9 V-Mount Lock Release Button: Press once to release the connection of the V-Mount
battery or NP-F battery plate.
BP Input Interface: You can provide a mobile power supply solution for the RC 100C
10
through the V-Mount battery or NP-F battery plate. It supports 125W V-Mount
battery input / 60W NP-F battery input.
Mini modifiers Release Button: Press once to release the connection of the mini
11
modifiers.
8
9
11
05
