Power Supply

EN
The RC 100C comes with BP interface / USB-C interface / mini XLR interface, allowing
direct connection to V-mount batteries / NP-F battery plate with NP-F970 batteries /
battery grips for mobile power supply, or continuous wall outlet power supply via PD
chargers / AC to DC adapters (optional).
To ensure fully output of the gear, it is recommended that users use V-mount batteries
of 98Wh or above (V-mount battery voltage should not exceed 35V) / USB-C PD power
supplies of 100W or above/AC to DC adapters to power the RC 100C. Additionally, when
powering the RC 100C with a USB-C PD power supply of 100W or above, please use a
USB-C to USB-C charging cable that complies with the PD 3.1 specification.
(The standard version includes a PD 3.1 charging cable)
Please note that if the power of the USB-C power supply is less than 100W, such as a
USB-C PD power bank providing only 45W output power, the illumination output of the
RC 100C will only reach around 45%. Furthermore, due to limitations in the peak output
of different brands of V-mount batteries / NP-F batteries, using batteries below the NP-
F970 specification or V-mount Battery below 98Wh may cause abnormal operation of
the gear/ battery. Using two NP-F970 batteries will only provide approximately 60% of
the maximum illumination output for the RC 100C.
The RC 100C features a low battery alert function. When the
external battery power is detected to be below 12V, a low
battery alert will be triggered. Please replace the battery
promptly or connect to another power source.

Overheating protection:

1. To ensure the long-term stable operation of the RC 100C,
it is recommended to store and use this equipment in
accordance with the temperature, humidity, and environment
mentioned in the "Important Prompt" The RC 100C features
a built-in overheating protection function. If the temperature
of the COB Chip exceeds the limitation of 100℃/ 212℉, the
gear will activate overheating protection status.
2.If the screen displays "Sensor error," it indicates a malfunction
of the temperature sensor in the device, and the equipment will
cease operation. Please contact the dealer from whom you
purchased the device for post-purchase repairs.
