a. Assembly Chart
The airplane already pre-assembled almost 90% in factory and Little
to do before flight. Please refer to the following assembly steps if you
need to chek or repair your aeroplane.
GB
1
At the tailplane evenly coated with adhesive white glue
3
At the bottom of the fin evenly coated with white glue
5
Adjust the fin and tailplane in vertical 90 degree. Then allow the glue
to cure.
36 CARSON Spy Hawk • 50 050 5019 + 20 + 21 + 22
For to build the model, please using an appropriate glue for foam
materials. We recommend 2-component epoxy glue.
2
The tailplane bonding to the body firmly
4
Bonding the fin to the body firmly
6
Connect the servo rod to the Elevator servo angle.
Clip here
