2. OPENING THE CHASSIS
2a. Lift the handle in accordance with image 2a
2b. When opening the chassisin accordance with image 2b, you shou d hear a click on both sides of
the chassis;before using the strol er, please check the chassisis secured in a safe position.
3. AFFIXING / REMOVING
3a. Affixing rear wheels: affix the rear wheel on one side by inserting the rear axle into the slot in the
plastic section in accordance with image 3a until it fits all the way in.Then do the same to affix the rear
wheel on the other side.
3b. Removing rear wheels: pul out the metal ocking device in the direction of arrow I then remove
the rear wheel in the direction
4. AFFIXING / REMOVING
4a. Affixing front wheels: affix the front wheel on one side by inserting the sloping axle into the slot
in the plastic section in accordance with image 4a until it fits all the way in.Then do the same to affix
the front wheel on the other
4b. Removing front wheels:
time pulling the front wheel out in the direction of arrow 2 with your other hand.
5a.360 degree swivel front wheels
Tofix your front wheels, move the locking device upwards, and to releasethe swivel front wheels move
the ocking device downwards, as shown in image 5a. Check to ensure the front wheels can free y
swivel in the unlocked position.
5b. Braking the stroller
n order to brake your strol er,pressdown on the brake pedal.To releasethe brake,lift the pedal up, see
image 5b.
Caution: When placing your child in the stroller or removing them from it, always have the
brake engaged.
7a. Attaching the bumper
nsert the bumper bar into the holders on both sides of the set unit asshown in image 7a.
Note: ensurethe bumper bar is correctly affixed in place a click should be heard.
7b. Removing the bumper bar
To remove the bumper bar, pressthe button as shown by arrow 1 in image 7b. Remove the bumper
bar in the direction of arrow
8a. Affixing the canopy
Attach the canopy to the seat unit as shown in image 8a.
8b. Folding and unfolding the canopy
Fod and unfold the canopy as shown in image 8b.
9. Adjusting the handle
Pressthe button as shown by arrow 1 in image 9 and set the required pos•tion asshown by arrow 2.
I Oa. Setting the foot rest
To set the foot rest,pressthe ocking device on both sidesof the foot rest as shown by arrow I in
image 10 and set the required position (3 foot rest positions).
11a. Beck rest position
Usethe ocking device as shown by arrow 1 in image la to set the position of the backrest in one of
3 positions as shown in •mage I I b.
12a. Reversing the seat unit
Pressthe ocking devices on both sides of the seat unit and lift the seat unit in the direction of the
arrow in •mage 12a,then affix the seat unit to the chassisfacing the opposite way as shown in image
12b.
:
REAR WHEELS :
of arrow 2.
FRONT WHEELS :
side.
press the smal metal pin in the direction of arrow I, whi e at the same
bar
2.
