Jungle Gym Bridge Module 2.1 Montageanleitung Seite 33

07 Bridge Frame
BF03/04
BF23/24
Base Tower 115
L
( BT07 - BT15 )
R
Base Tower 140
( BT19 - BT20 )
07-1 Bridge Frame 115
BF03
Assembly Pack: 194_007 (a) / 194_802(b)
PartNo
001_411 Stealth Screw 8x60
Hardware
002_220 Gap Point Screw T25 - 5x45
+
Parts
002_223 Gap Point Screw T25 - 5x80
C56 Beam 560 mm
C74 Beam 740 mm
C114 Beam 1140 mm
Timber
C141 Beam 1410 mm
D65 Board 650 mm
Design Code: mRxu0D © 2025 Jungle Gym B.V. Copyrighted material. All rights reserved. Single-owner licensed. No part of this document may be reproduced or utilized otherwise
in any form or by any
SW file: Manual Modular ClatterBridge.v5
SW file: Manual Modular ClatterBridge.v5
PartName
means, electronic or mechanical, including
X
L
R
07-1
33
07-9
37
QTY.
1
10
Ø3.5mm
12
1
1
1
2
photocopying, or posting on the internet
L
R
07-5
35
07-14
40
L
!
SAFETY
SW file: Manual Modular CL_BridgeFrame_v2
or an intranet, copying and networking
33
