Jungle Gym Bridge Module 2.1 Montageanleitung Seite 30

06 Clatter Bridge
CB01-part01
Assembly Pack: 194_011
PartNo
002_220 Gap Point Screw T25 - 5x45
002_223 Gap Point Screw T25 - 5x80
002_308 Gap Point Screw T25 - 5x20
Hardware
+
Parts
022_911 Bridge Spacer
023_031 Finishing Washer GPS 5.0
121_114 BridgeLink Strap 210cm
C141 Beam 1410 mm
D60 Board 600 mm
Timber
D141 Board 1410 mm
06 -1
L
R
30
Design Code: mRxu0D © 2025 Jungle Gym B.V. Copyrighted material. All rights reserved. Single-owner licensed. No part of this document may be reproduced or utilized otherwise
in any form or by any means,
PartName
electronic or mechanical, including photocopying,
QTY.
10
12
72
3.5 mm
26
72
3
2
12
2
or posting on the internet
!
SAFETY
SW file: Manual Modular ClatterBridge.v5
or an intranet, copying and networking
SW file: Manual Modular ClatterBridge.v5
prohibited.
