Jungle Gym Bridge Module 2.1 Montageanleitung Seite 29
Teil 2 aktivitätsspielzeug zum zusammenbauen durch erwachsene für den einsatz im häuslichen außenbereich
05 Balustrade
BL02
Assembly Pack: 194_101
PartNo
002_220 Gap Point Screw T25 - 5x45
Hardware
+
Parts
002_223 Gap Point Screw T25 - 5x80
C74
Beam 740 mm
Timber
D65
Board 650 mm
05-1
C74
80
!
