7.3 Clone mode (clone data from source SSD to target SSD)
Important:
– Data will be copied from "Source SSD1" to "Target SSD2".
– All existing data on the "Target" drive will be lost.
– Always back up important data before cloning.
– Do not remove a drive or disconnect the power supply during cloning.
Note:
– For clone mode, you don't need to connect to a PC.
– The capacity of the target SSD must be greater than or equal to that of the source SSD.
1. Insert the source SSD with data into the Source SSD1 slot, and insert the target SSD into
the Target SSD2 slot.
2. Connect to power with DC IN port. Press the power button (2).
The corresponding SSD indicator will light up white.
Æ
If the SSD is defective, the corresponding SSD indicator light will flash red.
Æ
3. Press and hold the clone button (7) for 3 to 5 seconds.
The clone process lights (25%-100%) begin to flash.
Æ
4. Press the clone button (7) again.
The clone process lights (25%-100%) will flash in turn and in cycles, the SSD lights will
Æ
also flash, and the cloning process will begin.
When 25% , 50%, 75%, and 100% lights all turn solid and the SSD lights are on, the
Æ
cloning process is complete.
5. Press the power button (2) to power off. Then remove the SSDs.

8 Cleaning and care

Important:
– Do not use aggressive cleaning agents, rubbing alcohol or other chemical solutions.
They damage the housing and can cause the product to malfunction.
– Do not immerse the product in water.
1. Disconnect the product from the power supply.
2. Clean the product with a dry, fibre-free cloth.
9 Disposal
This symbol must appear on any electrical and electronic equipment placed on the
EU market. This symbol indicates that this device should not be disposed of as
unsorted municipal waste at the end of its service life.
Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose
of it separately from unsorted municipal waste. Spent batteries and accumulators,
which are not enclosed by the WEEE, as well as lamps that can be removed from
the WEEE in a non-destructive manner, must be removed by end users from the
WEEE in a non-destructive manner before it is handed over to a collection point.
Distributors of electrical and electronic equipment are legally obliged to provide free take-back
of waste. Conrad provides the following return options free of charge (more details on our
website):
in our Conrad offices
at the Conrad collection points
at the collection points of public waste management authorities or the collection points set
up by manufacturers or distributors within the meaning of the ElektroG
End users are responsible for deleting personal data from the WEEE to be disposed of.
It should be noted that different obligations about the return or recycling of WEEE may apply in
countries outside of Germany.

10 Technical data

10.1 Power adapter

Input.............................................. 100 - 200 V/DC, 50/60 Hz, max. 0.5 A
Output ........................................... 5.0 V 3 A 15 W
10.2 Product
Input.............................................. 5 V/DC, 3 A via USB-C
Interface ........................................ USB-C
Data transfer speed ...................... Up to 10 Gbps
System requirement ..................... Windows
10.3 Supported SSD
Type .............................................. M.2 NVMe (M-Key) SSD
Size ............................................... 2230/2240/2260/2280/22110 mm
Storage capacity ........................... Max. 4 TB (2 TB x 2)
Memory size ................................. Max. 8 TB
10.4 Other
Operating temperature ................. 0 to +70 °C
Operating humidity ....................... 10 – 80 % RH (non-condensing)
Storage temperature ..................... -10 to +80 °C
Storage humidity ........................... 8 – 90 % RH (non-condensing)
Material ......................................... ABS
Dimensions (W x H x D) ............... 79 x 19 x 77 mm
Weight .......................................... 157 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights in-
cluding translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represents the technical status at the time of printing.
Copyright 2025 by Conrad Electronic SE.
®
®
, macOS, Linux
®
