b) Standalone cloning
You can create up to 3 backups of a source drive without connecting to a computer.
Important
• Make sure the drive containing your data is in the bay marked "Source", and the
empty drive(s) in a bay marked "Target".
• Make sure you back up any important data on the "target" drive(s) before cloning.
• The target drive should have a larger capacity than the source.
• Moving the station during operation can damage connected drives and/or cause
loss of data.
• Format drives before use. Choose the MBR format for drives ≤ 2 TB, and GPT for
drives > 2 TB.
• Press RESET or restart the station each time you switch modes: Clone ↔ PC.
1. Connect one end of the power adapter to the DC power input on the station, and the other
end to a power outlet.
Make sure the USB cable is not connected. Cloning will not begin if it is attached.
2. Insert the drive containing your data into the Source bay.
3. Insert the empty drive(s) into an available Target bay(s).
4. Set the mode switch to Clone.
5. Press the button to turn the power ON. The station will perform a self check then beep
twice to indicate it is ready to clone.
6. Press the START button twice to begin cloning.
- The LED status indicator will flash blue and red during cloning.
- Three short beeps will indicate cloning complete, and all LED status indicators will remain
on.
7. When finished using, press the
8. Remove any connected drive(s).

Troubleshooting

Problem Suggested solution
Make sure the USB cable is not connected. Cloning will
not begin if it is attached.
Cannot clone
Check that the target drive capacity is larger than the
source, the target drives are formatted, and the format-
ting is the same for all drives.
• Check the USB cable connection.
Docking station not recognized • Try a different port.
by computer.
• Make sure the power adapter is connected and
Docking station disk not appear-
Check that the drive is formatted, and the formatting is
ing as a removable drive on
supported by your operating system.
computer.
Cannot turn the station power Check the power adaptor, the power LED will light up
on. when it is receiving power.
button to turn the power OFF.
receiving power.

Care and cleaning

• Disconnect the product and remove and inserted drives before each cleaning.
• Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as
they can cause damage to the housing and malfunctioning.
• Clean the product with a dry, fibre-free cloth.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the house-
hold waste. At the end of its service life, dispose of the product in accordance with
applicable regulatory guidelines.
You thus fulfill your statutory obligations and contribute to the protection of the envi-
ronment.

Technical data

a) General
Input voltage/current ..................... 12 V/DC, 6.5 A
Hot swapping ................................ yes
Plug and play ................................ yes
USB .............................................. 3.2 Gen 1x1
Number of bays ............................ 4
HDD Interface ............................... SATA I,II,III
Supported HD capacity ................. max. 4x 10 TB = 40 TB
Supported HD types ..................... HDD/SSD
6.35 cm (2.5")
8.89 cm (3.5")
Transfer speed rate ...................... max. 5 Gbps (SATA III and USB 3.0)
Clone transfer rate ........................ max. 5 Gbps (SATA III and USB 3.0)
Supported OS ............................... Windows
above, Linux 2.6.39 and above
Operating conditions ..................... 0 to 40 ºC, 10 – 90 % RH (non-condensing)
Storage conditions ........................ -20 to +60 ºC, 10 – 90 % RH (non-condensing)
USB cable ..................................... 102 cm
Dimensions (W x H x D) ............... 217 x 78.3 x150 mm
Weight .......................................... 983 g
b) Power adapter
Input ............................................. 100 - 240 V/AC, 50/60 Hz 2 A max.
Output ........................................... 12 V/DC, 6.5 A
Length of cable ............................. 118 cm (w/o plug)
Length of power cord .................... 113 cm (w/o plug)
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights in-
cluding translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represent the technical status at the time of printing.
Copyright 2020 by Conrad Electronic SE.
XP or above (32 & 64 bit), Mac OS 9.1 and
®
