E) LED status indicator (- 6 -)
LED: AC Power (01)
OFF =
RED =
LED: Charging status (02)
RED =
GREEN =
OFF =
RED (flickering) =
LED: Battery usage (03)
BLUE =
OFF =
LED: Discharge status (04)
GREEN =
OFF =
F) Warnings
► Pay attention to the correct voltage values.
► Do not attempt to open the V-Mount 4Slot XLR Charger or the batteries.
► Do not alter or modify the product or its accessories.
► Stop using the product if it is damaged or if you notice any unusual odours.
► Protect the V-Mount 4Slot XLR Charger from moisture.
► Do not drop or cover the V-Mount 4Slot XLR Charger.
► The V-Mount 4Slot XLR Charger is not suitable for children.
► Protect the V-Mount 4Slot XLR Charger from extreme heat and cold.
► It is normal for strong heat to be generated during operation. Make sure that heat dissipation is
guaranteed.
► Disconnect the V-Mount 4Slot XLR Charger from the power source after use.
G) Warranty
The manufacturer is not liable for damage to property and/or personal injury resulting from impro-
per installation, maintenance, operation or applications. The warranty only covers the product itself,
as the manufacturer has no influence on the installation and use of the product.
no power supply
ready for operation
charging process
charge level 85%
fully charged
short circuit/overload
discharging process
battery low or connection problems
battery is used/discharged via XLR4P
battery is not used/discharged via XLR4
9
AC POWER
01
CHARGING
02
L1 R1
L2 R2
BATTERY ONLINE
03
L1 R1
L2 R2
DISCHARGING
04
L1 R1
L2 R2
