ICB-Q21-13-HMI
Technical Data
Cable Power Supply Unit Compatibility
Accessory
Power Supply Unit 950
Power supply unit compatible for up to 140 Nm.
Product Data
Motor voltage
Motor power
Speed
Torque range
Weight
Product Power Source
This product can be used with either a battery, or with an
electrical power cable in combination with a power supply
unit.
Charger Temperatures
Charger operating tempera-
ture
Maximum Radio Output Power
Frequency Range
Radio Technology (MHz)
Wi-Fi® 2402-2480
Wi-Fi® 5180-5320
Wi-Fi® 5500-5700
Bluetooth® wire- 2402-2480
less technology /
Bluetooth® Low
Energy
Wi-Fi® is a registered trademark of Wi-Fi Alliance®
The Bluetooth® word mark and logos are registered trade-
marks owned by Bluetooth SIG,Inc.
Wireless LAN Information
Regulatory Do- Band
main
ETSI 2.4 GHz
U-NII-1
U-NII-2
U-NII-2e
Article No.
8432084006
35 V d.c.
500 W
897 r/min
3.4 - 13 Nm (2.5 - 9.6 ft lb)
1.02 kg (2.25 lb)
+5 to +40 °C
(+41 to +104 °F)
Maximum Trans-
mit Power EIRP
(dBm)
19.46
20.37
18.39
9.29
TxChannels
1, 2, 3, 4, 5, 6, 7, 8,
9, 10, 11
36, 40, 44, 48
52, 56, 60, 64
100, 104, 108, 112,
116, 120, 124, 128,
132, 136, 140
© Atlas Copco Industrial Technique AB - 9846 0416 00
2.4 GHz
FCC/IC
U-NII-1
U-NII-2
U-NII-2e
U-NII-3
Charger Compatibility
Accessory
Flex charger
Battery Compatibility
Accessory
Battery, 14V (2.5Ah)
Battery, 18V (2.5Ah)
Battery, 18V (2.5Ah)
Battery, 36V (2.5Ah)
Battery, 36V (2.5Ah)
EU SAR value
EU SAR Value: 0.55
Ambient Temperature
For best battery performance and life time, keep battery
within temperature intervals.
Operating temperature, charge
Operating temperature, discharge
Transportation temperature
Storage temperature
Do not place battery in direct sunlight.
Declarations
Liability
Many events in the operating environment may affect the
tightening process and shall require a validation of results. In
compliance with applicable standards and/or regulations, we
hereby require you to check the installed torque and rotational
direction after any event that can influence the tightening re-
sult. Examples of such events include but are not limited to:
• initial installation of the tooling system
• change of part batch, bolt, screw batch, tool, software,
configuration or environment
Safety Information
1, 2, 3, 4, 5, 6, 7, 8,
9, 10, 11
36, 40, 44, 48
52, 56, 60, 64
100, 104, 108, 112,
116, 132, 136, 140
149, 153, 157, 161,
165
Article nr.
4211 6083 84
Article nr.
4211 6130 02
4211 6030 85
4211 6130 06
4211 6030 86
4211 6130 14
+5 to +40 °C
(+41 to +104 °F)
0 to +40 °C
(+32 to +104 °F)
−20 to +40 °C
(−4 to +104 °F)
+10 to +25 °C
(+50 to +77 °F)
