NOTICE Only Use Angle Heads Compatible with the Tool
Using the wrong type of angle head can cause incorrect tightenings and inaccurate torque calculations.
NOTICE Use the Correct Maximum Torque, Gear Ratio and Efficiency Tuning for the Angle Head
Using the wrong maximum torque can break the angle head. Using the wrong gear ratio and efficiency tuning can cause incorrect
tightening and inaccurate torque calibration.
Use the maximum torque, gear ratio and efficiency tuning stated on the angle head. The technical data for the angle head can
►
also be found on ServAid. If the efficiency tuning is not stated on the angle head, it should be set to 1.
Article number Angle head
8436001000 Q2-A7-06
8436001017 Q2-A7-HAD
8436001002 Q2-Z7-06
8436001004 Q2-A15-10
8436001006 Q2-A12-06
8436001008 Q2-A20-10
8436001015 Q2-A15-HAD
8436001010 Q2-Z15-10
8436001012 Q2-Z12-06
8436001014 Q2 Adapter BK22
2
Quick change Torque
interface range (Nm)
IQ-7 1.4-7
IQ-7 1.8-7
IQ-7 1.8-7
IQ-13 4-15
IQ-13 4-12
IQ-13 5-20
IQ-13 4-15
IQ-13 4-15
IQ-13 4-12
IQ-7/IQ-13
© Atlas Copco Industrial Technique AB - 9846 0416 00
ICB-Q21-13-HMI
Weight (g) Compatible tools
150
ICB-Q21-07
(8436003007)
ICB-Q21-07-HMI
(8436003008)
200 ICB-Q21-07
(8436003007)
ICB-Q21-07-HMI
(8436003008)
180 ICB-Q21-07
(8436003007)
ICB-Q21-07-HMI
(8436003008)
190
ICB-Q21-13
(8436003013)
ICB-Q21-13-HMI
(8436003014)
190 ICB-Q21-13
(8436003013)
ICB-Q21-13-HMI
(8436003014)
220 ICB-Q21-13
(8436003013)
ICB-Q21-13-HMI
(8436003014)
200 ICB-Q21-13
(8436003013)
ICB-Q21-13-HMI
(8436003014)
180
ICB-Q21-13
(8436003013)
ICB-Q21-13-HMI
(8436003014)
180 ICB-Q21-13
(8436003013)
ICB-Q21-13-HMI
(8436003014)
110 ICB-Q21-07
(8436003007)
ICB-Q21-07-HMI
(8436003008)
ICB-Q21-13
(8436003013)
ICB-Q21-13-HMI
(8436003014)
