Costway TQ10167DE Bedienungsanleitung Seite 8

6
1
1
4
D
14
Figure 6:
Sequentially install the
gear box (6), rear
D
A
driving wheel (5),
12
washer (D), locknut
(A) , wheel cover (12)
Note: After the rear
wheel is installed,
connect the motor
wires.
Figure 7:
Sequentially install the
washer (D), front
wheel (4), washer (D),
D
A
locknut (A), wheel
12
cover (12)
Figure 8:
Connect the steering
wheel wires and install
the steering wheel (3).
Figure 9:
Install the
10
rearview
10
mirror (10)
on the
1
left side
1
Figure 11:
Install the seat (16) to
the corresponding
16
place
Note: Connect the
battery wires first, then
install the seat.
Figure 12:
Lock the seat with the
latch (I)
I
Figure 10:
Install the
rearview
mirror (10)
on the right
side
15
