Note: 4 wheels of NO. 4 and 5 are the same.
Component List
1 pre-assembled car body
2 steering frame
3 steering wheel
4 front wheel
5 rear wheel
6 gearbox
7 spare tire
8 steering axle
10
ASSEMBLY
9 windshield
x1
10 rearview mirror
x1
11 rear axle
x1
12 wheel cover
x2
exhaust pipe
13
x2
14 parental remote
x2
15 battery charger
x1
16 seat
x1
A
M10 locknut
4 on wheels,
2 on steering frame
D
12MM washers
4 on steering frame
2 on rear axle
2 spare
F
tapping flat head screw
4mm*12mm
exhaust pipe
I
seat's latch
seat
K tapping flat head screw
REMARKS: Cotter pin (C) /10MM washer (G) / seat's latch (I)
x1
is in the screw package. Other tapping flat head
screw\locknut\washers were fixed on the part that you need
x2
assemble.
x1 Assembly of your new car is simple, provided you carefully
follow the detailed diagram and refer to component part
x4 numbers to ensure they are fitted in the correct order as
shown above.
x2
x1 IMPORTANT!
Before the first time use, charge the battery for 10 hours.
x1
Never charge the battery longer than 20 hours.
x1
C
x6 cotter pin
E
x8 wrench
G
x4 10MM washer
J
x1 tapping flat head screw
4mm * 16mm
rear axle
4mm * 14mm spare tire
x1
x2
x1
x8
x2
11
