WARNING:
The toy is to be assembled by an adult (or similar meaning).
Potential hazard description, e.g. In disassembled state, it
contains potentially hazardous sharp points, sharp edges and
small part, so please keep out of baby's reach.
Please remove the foam that protected the battery when
used!
Installation steps:
tapping flat head screw
4mm * 12mm
12
Figure 1:
Install the windshield
windshield
9
(9)
Figure 2:
Install the exhaust
pipe (13) with 4
screws (F)
13
exhaust pipe
A A
rear axle
11
Figure 3:
Install the steering
frame (2) and fix it with
locknut (A)
Figure 4:
The steering axle is
inserted into the front
shaft iron plate and
fixed with cotter pin
and 10mm washer
Figure 5:
Fix the real axle (11)
with 8 screws (J)
tapping flat head
J
screw
4mm * 16mm x8
