Backrest Misalignment
01
Remove the backrest side covers.
Using the provided Allen key, loosen all
four of the M8 screws that attach the backrest
to the seat base such that there is
enough room to wiggle the backrest.
03
Adjust the backrest until it is aligned,
then hold it in position. While continuing
to hold the backrest in position, fully tighten
the M8 screws on the RIGHT side first.
It is possible for your backrest to be misaligned while assembling the backrest
to the seat base. While this does not affect the use and stability of the chair,
it can be corrected in a few steps.
02
Pull the right side (while facing the front of
the chair) of the backrest towards you, while at
the same time pushing the left side of the
backrest away from you.
04
While holding the backrest in position, fully tighten
the M8 screws on the LEFT side. You may have to push
the left side of the backrest in the direction as shown
in Step 2, until the desired alignment is achieved.
Please note that slight variations in stitching alignment or symmetry between
the backrest and seat base are to be expected.
