use in height range 76-87 cm); 7. Shoulder strap; 8. Harness buckle; 9. Crotch strap; 10. Harness adjusting lever; 11.
Harness adjustment strap; 12. Lab belt guide
FIGURE C: To adjust the head support, pull and hold the head support release handle. Pull the handle up to move the
head support to a higher position. Hold the handle and push the head support down to move it to a lower position.
When the head support is in the desired position, release the handle to lock it.
FIGURE C.1: The head restraint must be adjusted so that the straps of the 5-point harness are at the same height or
slightly above the child's shoulder
Step 1: Hold down the harness adjustment button and pull the shoulder belt towards you as far as possible. Make sure
to pull the shoulder belt under the chest pads.
Step 2: Press the red button on the 5-point belt buckle to unbuckle it.
Step 3: Put the child to sit in the seat. Slide the shoulder belts over the child's shoulders and tuck the tongues of the
buckle into each other. Lock the tucked tongues into the buckle.
Step 4: Pull both shoulder belts to tighten the lap belt. Make sure the lap belt is positioned low down so that the child's
pelvis firmly gripped.
Step 5: Pull up on the 5-point belt adjuster until the belt secures the child properly. Pull the two chest pads to the
lowest position.
ATTENTION! The 5-point safety harness of car seat must be removed when child reaches height 100-150 cm.
Step 1: Unlock the belt from central buckle, remove the crotch pad and insert the buckle through the slot of fabric
cover.
Step 2: Press and hold the button for shoulder belts adjustment. Remove the cover at the back of backrest, pull the
metal joint and split the shoulder belt from it. Place the metal joint into the slots of car seat and tighten it to prevent
falling.
Step 3: Lift the cover of head support and pull the shoulder belts at front to remove them.
Use the chair's 5-point safety harness to ensure your child's safety.
Place the car seat on the passenger seat in "FORWARD facing position.
1.Pass the diagonal belt of the vehicle through the shoulder belt guide and both belts guiding devices. The lap belt
pass through the guides at the bottom of the seat.
2. Fasten 3-point safety belt of the vehicle into the buckle of passenger seat, until you hear "click "sound, then tighten
the belt.
3.Place the child in the car seat, fasten 5-point harness system and tighten, using the harness adjusting lever.
ATTENTION! The 5-point safety harness of car seat must be removed when child reaches height 100-150 cm.
Use the 3-point safety belt of the vehicle to ensure your child's safety.
Place the car seat on the passenger seat in "FORWARD facing position.
1.Place the child in the car seat and set the height of head support based on the child's height.
ATTENTION! Suitable headrest height is when the diagonal vehicle belt pass right over the child's shoulder.
2.Pull the 3-point safety belt of vehicle.
3.Thread the diagonal belt though the guide of head support, and the lap through the guide of base and lock them
into the vehicle buckle.
HEAD SUPPORT ADJUSTMENT - FIGURE C
(about 1.5 - 2 cm/one finger above the child's
PUTTING A 5-POINT SAFETY HARNESS- FIGURE D
REMOVING THE 5-POINT SAFETY HARNESS- FIGURE E
CHILD SEAT INSTALLATION IN FORWARD FACING POSITION - FIGURE F
CHILD'S HEIGHT: 76-105 cm
Using: 5-point safety harness + 3-point safety belt
CHILD SEAT INSTALLATION IN FORWARD FACING POSITION - FIGURE G
CHILD'S HEIGHT: 100-150 cm
INSTRUCTIONS FOR MAINTENANCE AND CLEANING
- FIGURE B.3
- FIGURE B.1
- FIGURE B.1
Using: 3-point safety belt
shoulder).
