ENGLISH
Présentation
A - Swivel-to-mute microphone
B - Status LED
C - Mode switch
D - Volume wheel
E - USB-C charge port
Charging
It is recommended to fully charge your headset before rst use.
CHARGE STATUS
Fully Charged
0% — 99%
Usage
Adapter Mode
1. Slide mode switch to
mode.
2. Connect the USB wireless dongle to a PC or game console.
3. Power ON the headset.
Bluetooth Mode
1. Slide mode switch to
mode. The headset will ash blue on the rst setup.
2. Go to your device Bluetooth settings, search, and connect to "HyperX Cloud
Jet".
Bluetooth Pairing
1. Slide mode switch to
mode. Power OFF the headset.
2. Press and hold the multifunction button for 5s. Pairing mode is active when the
LED blinks blue and the voice prompts says, "Bluetooth pairing."
3. Go to your device's Bluetooth settings and connect to "HyperX Cloud Jet".
Setup
Windows 11
To ensure the headset is con gured correctly on the PC, follow the steps below:
1. Right-click on the sound icon in the system tray and select Sound Settings.
2. Set the output device to Headphones [HyperX Cloud Jet].
3. Set the input device to Microphone [HyperX Cloud Jet].
PlayStation 5
Go to the home page and select Settings > Sound.
Microphone
Input Device: USB Headset "HyperX Cloud Jet".
Audio Output
Output Device: USB Headset "HyperX Cloud Jet".
Output to Headphones: All Audio.
F - Multifunction button
G - USB wireless dongle
H - Pairing pin hole
I - USB-C to USB-A charge cable
STATUS LED
Solid green
Breathing green
Controls
Status LED
STATUS
Adapter Mode: Blinking-fast white
Pairing
Bluetooth Mode: Blinking-fast blue
Searching
Connected
Bluetooth Mode: Solid blue for 5s
Low Battery
Multifunction Button
Power on/o - Hold button for 2 seconds to power headset on/o .
Media controls:
o 1 x Play/Pause
o 2 x Play next song
o 3 x Play previous song
Volume Wheel
Scroll up and down to adjust volume level.
Swivel-to-Mute Microphone
Questions or Setup Issues?
Contact the HyperX support team or see the user manual at
hyperx.com/support
WARNING: Permanent hearing damage can occur if a headset is used at high
volumes for extended periods of time.
Battery Replacement
1. Power OFF the headset.
2. Carefully pull the left ear cushion from the headset.
3. Unscrew the 4x Philips screws to separate the driver cover from the left earcup.
4. Gently separate the cover from the earcup to avoid any damage.
5. Locate and remove the battery secured with a connector.
6. Place new battery matching correct pin orientation.
7. Close the driver cover and earcup. Reverse steps 3 and 2. Make sure to push
cushion into the slot all around the earcup.
8. Power ON the headset and test for functionality.
LED
Adapter Mode: Blinking white
Bluetooth Mode: Blinking blue
Adapter Mode: Solid white for 5s
< 10%: Blinking red every 3s
