REMOVING THE COVER FOR THE CONNECTION TERMINAL
The transparent cover for sealing the connection terminal is mandatory for outdoor installation;
the cover can be optionally used for indoor installation.
1 Take the cover for sealing the connection terminal off the subwoofer (loosen the four Allen screws
with a suitable tool).
Pierce the centre of the rubber membrane of the rubber cable bushing with a pointed object
2
(for example, Phillips screwdriver) and insert a suitable round cable (5 to 9 mm outer diameter mains
cable and network cable).
Pull the cable outwards a short distance until the sealing lip of the rubber cable bushing folds in.
3
2
3
1
