4. Headrest adjustment.
The headrest adjustment system is based on the operation of a gas spring, after releasing the yellow lever, set
the headrest in the desired position.
For horizontal movement (traction), unlock the knob on the right side of the headrest frame. After finishing
work in this segment, lock the knob according to the diagram.
5. Adjusting the armrests.
Adjustment is made by releasing the lock and moving the armrest to the desired height.
6. Using the drop function.
Before starting the drop techniques, lay the patient on his stomach, make sure that the patient's position is
safe, all belaying elements (belts, headrest, armrests) have been adjusted to the patient's anatomy.
The technique should be performed only by qualified personnel, improper execution of the technique may
result in permanent injury to the patient.
Drop for the cervical section (Fig. 6).
Raise the cervical section using the lever located at the front of the headrest.
Perform the cervical vertebrae drop technique by rapidly and vigorously compressing the cervical segment,
which will force the cervical section of the table to drop.
Fig. 1 Fig. 2
Fig. 3 Fig. 4
Fig. 5
