- the device is no longer working,
- after it has been stored for a long time in less than ideal conditions,
- after the device has been transported under less than ideal conditions.
• Do not use or store the device in an environment at high temperatures, in hu-
mid, explosive or flammable environments, or one with high electromagnetic
fields. This could reduce the device's efficacy.
• In order to prevent damage to the testing device and prevent risks causing
possible accidents, the multimeter's internal circuit must not, under any
circumstances, be modified.
1
2
• FUNCTION SWITCH : OFF, buzzer continuity and diode, Ω Ohmmètre,
V (DC voltage), V~ (AC voltage), mA ~ (Direct and alternating current).
• HOLD key : Saves the current measurement, the HOLD symbol will
appear on the LCD screen and the displayed value will be saved. Press the
HOLD key to keep the current measurement and press the key again to
return to the normal display.
• FUNC key : toggles between DC and AC ammeter functions, and between
continuity and diode test.
• 2 in 1 clip: holds the test leads in place in
the cover and serves as a support for installation.
1
AUTO
2
DC
3
AC
4
~
5 6 7
hFE
HOLD
3
4
5
6
1. Automatic calibration
2. DC voltage
3. Negative polarity
4. AC voltage
8
+
-
5. Diode test
kM
6. Buzzer continuity
°C
7. Hold active mode
9
A
mV
µ 8. Low battery symbol
9. Unit of measurement
NOTE: before
using for the first
time, remove the
protective tab on
the batteries
1. Test leads
2. LCD display
3. 2 in 1 clip
4. FUNC key
5. HOLD key
6. Function switch
