Dell™ PowerEdge™ C1100—
Information Update
Support for 6 Gb/s SAS Interface
Your system supports 6 Gb/s SAS expander board for 2.5" hard drives and
6 Gb/s SAS backplane for 3.5" hard drives. 6 Gb/s SAS is based on the SAS–2
specifications and extends the data-transfer rates from previous 3 Gb/s to 6 Gb/s.
3.5" Hard-Drive Systems Backplane
1
16 15
1 8-pin fan connector 6
3 8-pin fan connector 5
5 8-pin fan connector 3
7 8-pin fan connector 1
9 SATA 3 connector
11 SATA 2 connector
13 SATA 1 connector
15 SATA 0 connector
February 2010
3 4
2
14 13
2
4
6
8
10 hard-drive 4 connector
12 hard-drive 3 connector
14 hard-drive 2 connector
16 hard-drive 1 connector
6
5 7
12 11
SGPIO signal cable
8-pin fan connector 4
8-pin fan connector 2
power connector
8
10 9
