NOTE: If using a non-Humanscale worksurface,
pilot holes for mounting the front hooks should be
drilled in line with the rear hook holes according to
the following diagram:
3
Once the hooks are installed, hang the short
side of the basket from the rear hooks with the
plastic tabs at the bottom, as shown below.
Ensure that the hook-and-loop fastening strips
face the front of the desk.
4
Secure the power strips, cables and other
peripherals within the basket using the
hook-and-loop fastening strips.
WARNING: The installation/operating
instructions of items placed within the
basket must be followed. The fastening
strips should not obstruct the insertion
of plugs into any items with receptacles.
Plugs and/or power adapters must be fully
seated. Max. load: 15lbs
5
Once the cables are secured, lift the plastic tabs
and secure them to the front hooks to complete
installation.
①
15mm (0.6")
83.85mm (3.3")
②
③
④
3
