PROFIBUS PA Installation

Prinzipieller Aufbau einer PROFIBUS-Anlage:
Der elektrische Anschluß des Moduls an PROFIBUS PA erfolgt entsprechend der
PROFIBUS Guideline, Order No. 2.092 (www.profibus.com).
PROFIBUS-Kabel
18

Control room

...... ..... .....
PA+ (rot)
PA- (grün)
Schirm
z.B. Protos 3400(X)
mit Modul
COMPA 3400(X)-081
Modul COMPA 3400(X)-081
14
