Language/Clock

Steps 1 and 2 are common operations for each item.
1
Display the menu screen.
„When stopped
Press .
„When operating
Press repeatedly until the menu screen is displayed.
• To return to the top screen, press
2
Select the item to set.
Press →
Language
3
Select the language to display from among
7 languages shown on the right.
Press →
• Default setting: ENGLISH
Clock
3
Set the present date and time.
Press →
(Repeat)
• [--] appears in situations where the clock is reset, such as when power is
not supplied to the remote controller for 24 hours or more.

Specifications

Model No.
Dimensions
Weight
Temperature/Humidity range
Power Source
Precision
Clock
Holding time
Number of connected indoor units
OS version on the mobile device
for "Panasonic H&C Control App"
Bluetooth ® version
Wireless LAN standard
Frequency range
Encryption
OS version on the mobile device for
"Panasonic Comfort Cloud" app
6
.
.
→ .
(Press to finish.)
→ .
(Press to finish.)
CZ-RTC6BLW2 / CZ-RTC6WBLW2
(H) 86 mm x (W) 86 mm x (D) 25 mm
0.10 kg
0 °C to 40 °C / 20% to 80% (No condensation) * Indoor use only.
DC16 V (supplied from indoor unit)
± 30 seconds/month (at normal temperature 25 °C) * Adjust periodically.
24 hours (When fully charged) (at normal temperature 25 °C)
* Approx. 8 hours are required for full charge.
Indoor unit: Up to 8 units (Within group-controlling)
Check on the relative app store for supported OS versions.
4.2 or later
IEEE 802.11 b/g/n
2.4 GHz band
WPA™ / WPA2™ / WPA3™
Check on the relative app store for supported OS versions.
Total number of items
Number for the selected item
ENGLISH
РУССКИЙ
POLSKI
ESPAÑOL
ITALIANO
DEUTSCH
FRANÇAIS
