LED
D18
Forward / reverse
No focus
Stand-by
Parts and accessories
The Scoot Control is always accompanied by the D-P015-61-70-vv Scoot Control User
manual and the D-P015-61-71-vv Scoot Control Installation manual.
The following parts and accessories are optionally available:
PART NUMBER
P016-98 Actuator Keypad
Button R-net CJSM2
P016-99 Actuator Keypad
Paddle R-net CJSM2
P016-88 Actuator Keypad
PRO Button R-net CJSM2
P016-89 Actuator Keypad
PRO Paddle R-net CJSM2
M015-91 Scoot Control
keypad bracket set
14
FUNCTION
FUNCTION
You can connect an exter-
nal Curtiss-Wright CJSM2
compatible Actuator Key-
pad to the Scoot Control
R-net (P015-61) to con-
trol the actuators of the
power chair.
To mount an Actuator
Keypad to the Scoot Con-
trol
INFORMATION
In standard configuration:
Forward = green
Backward = orange
Off
Flash green / orange (depending on direction of
throttle)
See Scoot Control Installation
Manual
See
Scoot Control R-net User manual
INFORMATION
Dimensions on page 17
