BUTTON
S6
Hold S6 for > 2 sec-
onds
LED indications on the control panel provide you with the following information:
LED
D11-D15 Battery gauge
Speed setting
Out-of-neutral
Error
Status
D16 Left indicator
D17 Right indicator
D16 + D17 Hazard lights / lights
indicator
Scoot Control R-net User manual
FUNCTION
Speed setting
Grab focus
FUNCTION
Change the speed. The first click on S6 will
show you the current speed setting. The
next clicks will change the speed.
Press long to grab control of the power
chair. See Scoot Control Installation Manual
for more information.
INFORMATION
Battery indicator: is default on when Scoot Con-
trol is in focus
Speed indicator when setting the speed.
5 speeds = 5 green LED in a row (e.g. speed level 3
= 3 LEDs on)
Becomes active when pressing S6 and remains
active for 5 seconds after last speed change.
When the device is in out-of-neutral, D13 will be
lit continuously. Other LEDs are off.
D11 and D15 red, D13 flashes red, other LEDs
are off: number of flashes indicates the fault (see
Scoot Control Installation manual).
NOTE:
Only mo-vis faults are shown, R-net
system faults are shown on the remote.
• In focus: battery indicator
• Not in focus: D13 green heartbeat flash
• Configuration: D13 green fast flash
Green flash when left indicator is on
Green flash when right indicator is on
Both flash red when hazard lights are on. Both are
orange when the lights are on and the direction
indicator is off.
ACTION
