Setting Up Your Mounting Bracket
Dell™ OptiPlex™ 780-USFF Mounting Bracket
1
b
a
≥6.0"
(152.4 mm)
≥3.33"
(85 mm)
≥2.45"
(62.2 mm)
2x
≥13" ≥8.0"
(330.2 mm) (203.2 mm)
≥2.28"
M8 x 80 mm (58 mm)
Ø 3/16" (5 mm)
2
d e a b c d e
c f
M8 x 80 mm
2x
Ø 3/16" (5 mm)
DELL OptiPlex 780-USFF
≤ 7 lbs (3.2 kg)
3
1 2
a a
≥6.0"
≥6.0" (152.4 mm)
(152.4 mm)
≥6.0" (152.4 mm) ≥6.0"
(152.4 mm)
≥6.0" (152.4 mm)
≥6.0"
(152.4 mm)
≤4.25"
(108 mm)
≤4.25"
(108 mm)
≤4.25" (108 mm)
≤ .5" ≤ .5"
(12.7 mm) (12.7 mm)
