TURNING THE DRYWALL SANDER ON AND OFF
Make sure that the sander is switched OFF. Connect the sander to the power circuit. The drywall
sander is equipped with a ``rocker`` type switch. To start the drywall sander press the bottom
end of the switch button (ON). To stop the sander press the top end of the switch button (OFF).
This machine offers the option to attach an accompanying adapter to the back-end of the hose at
the guide tube, to fit a suction hose (for example the dry/wet vacuum cleaner from Jago) to the
machine, wherein the amount of dust will be minimized.
CAUTION: Inhaling dust can be dangerous to your health. Therefore wear a dust mask
while sanding.
• Refer to the figure labelled "Suction hose connection".
• Connect the hose (1) on both ends with the connectors (2+3), at which point the hose must
click-in to the connectors (see "Connection piece").
• Connect the thinner connection piece (2) to the handle (4).
(1)
(3)
DE FR EN ES EN

CONNECTING THE SUCTION HOSE

(2)
"Suction Hose Connection"
43
(4)
"Connection Piece"
