A10-12—Suction Inlet
A10-13—Cleaning Tray Module
A10-14—Dust Bag Slot
A10-15—Filter
A10-16—Dock Location Beacon
A10-17—Clean Water Dispensers
A10-18—Drying Air Outlets
Empty Wash Fill Dock (Back
A11
View)
A11-1—Power Cord Storage Slot
A11-2—Power Port
A11-3—Cord Outlets
Installation
B
Important Information
B1
B1-1—Tidy cords, hard or sharp objects
(such as nails and glass), and loose
items from the ground and move
any unstable, fragile, precious, or
dangerous items to prevent personal
injury or property damage due to
items becoming tangled in, struck by,
or knocked over by the robot.
B1-2—When using the robot in a raised area
(such as in a duplex apartment), always
use a physical security barrier to
prevent accidental falls that may result
in personal injury or property damage.
Notes:
• When using the robot for the first time, follow it
throughout its whole cleaning route and watch for
potential problems. The robot will be able to clean by
itself in future uses.
• To prevent excessive buildup of dirt on the mop cloths,
floors should be vacuumed at least three times before
the first mopping cycle.
Assembly
B2
B2-1—Attach the dock base by pressing
down both sides of the base and the
connecting part in the middle firmly
until you hear a click.
B2-2—Click
Note:
When moving the dock, secure the water tanks to
prevent them from falling off.
B2-3—Connect the power cord to the back
of the dock, and keep the excess
cord inside the storage slot.
Note:
Power cord can exit at either side.
B2-4—Align and install the mop axles into the
robot in place until you hear a click.
B2-5—Click
Positioning the Dock
B3
Place the dock on a hard, flat floor (wood/tile/
concrete etc.), flat against a wall, and reserve
a space of at least 0.9 m (2.96 ft) in height,
0.4 m (1.32 ft) in width and 1.2 m (3.94 ft) in
depth. Make sure that the location has good
WiFi coverage for a better experience with
the mobile app. Plug in and make sure that
the status indicator light is on.
007
B3-1—More than 0.9 m (2.96 ft)
B3-2—More than 0.4 m (1.32 ft)
B3-3—More than 1.2 m (3.94 ft)
Notes:
• If the power cord hangs vertically to the ground, it
may be caught by the robot, causing the dock to be
moved or disconnected.
• The status indicator light is on when the dock is
powered on, and off when the robot is charging.
• The status indicator light turns red if an error occurs.
• Place the dock on a hard, flat floor away from fire,
heat, and water. Avoid narrow spaces or locations
where the robot may be suspended in the air.
• Placing the dock on a soft surface (carpet/mat) may
cause the dock to tilt and cause docking and departing
problems.
• Keep the dock away from direct sunlight or anything
that may block the dock location beacon, otherwise
the robot may fail to return to the dock.
• Do not use the dock without clean water tank, dirty
water tank, dust container cover, disposable dust bag,
or cleaning tray module.
• Maintain the dock according to the Routine
Maintenance. Do not clean the dock power cord and
charging contacts with a wet cloth or tissue.
• All docks are subject to water-based tests before
leaving the factory. It is normal that a small amount of
water remains in the waterway of the dock.
Powering On & Charging
B4
Press and hold
to power on the robot.
Wait until the power indicator light is steady,
and then place the robot in front of the dock.
Make sure the dock is plugged in. Then,
press
and the robot will automatically
return to the dock for charging. The robot is
equipped with a built-in high-performance
lithium-ion rechargeable battery pack. To
maintain battery performance, keep the
robot charged.
