Robot Sensors
D8
* Clean as required.
Use a soft, dry cloth to wipe and clean all
sensors, including:
D8-1—Dock Locator
D8-2—Reactive AI Obstacle Recognition
Sensor
D8-3—Wall Sensor
D8-4—Communication Sensor
D8-5—Cliff Sensors
D8-6—Carpet Sensor
Moving the Dock
D9
To move the dock, grip the handle on the
back with one hand and the inner side of the
front board with the other hand. Do not lift
the dock base, water tank handles, or dust
container cover directly to prevent the dock
from falling off.
Dirty Water Tank
D10
* Clean as required.
Open the dirty water tank lid and pour out
the dirty water. Fill the tank with clean water,
close the lid, lock the latch, and shake. Pour
out the dirty water. Lock the lid and reinstall
the tank.
Notes:
• To avoid deformation, only use cold water.
• If any water stains remain on the outside of the
water tank, wipe them with a soft, dry cloth before
reinstalling the tank.
Charging Contacts
D11
* Clean as required.
Use a soft, dry cloth to wipe the charging
contacts on the robot and the dock.
Replacing the Disposable
D12
Dust Bag
* Replace as required.
D12-1—Remove the dust container cover.
D12-2—Remove the disposable dust bag
and discard it.
Notes:
• The dust bag handle seals the bag on removal to
prevent leakage.
• Always install a dust bag before putting back the dust
container cover to avoid auto-emptying without the
bag. You can also disable auto-emptying in the app.
D12-3—Clean the filter with a dry cloth,
insert a new disposable dust bag
into the slot all the way in, and
spread it evenly.
Note:
Make sure the disposable dust bag is properly
installed to avoid waste escaping and damaging the dock.
D12-4—Reinstall the dust container cover
in place to make sure the dust
container is securely sealed.
Cleaning Tray Module
D13
* Clean as required.
D13-1—Remove the cleaning tray module.
D13-2—Remove the cleaning tray and filter
from the module and then rinse
them with water.
011
D13-3—Reinstall the filter and cleaning tray.
Then, reinstall the cleaning tray
module.
Basic Parameters
Robot
Model
QX0VIM
14.4 V/6400 mAh (TYP)
Battery
lithium-ion battery
Rated Input
20 VDC 1.5 A
Charging Time
Approx. 4 hours
Note:
The serial number is on a sticker on the underside
of the robot.
Empty Wash Fill Dock
Model
EWFD30HRR
Rated Input Voltage 220-240 VAC
Rated Frequency
50-60 Hz
Rated Input (Dust
3 A
collection)
Rated Input
(Hot-water mop
5.6 A
washing)
Rated Input
0.6 A
(Charging & drying)
Rated Output
20 VDC 1.5 A
