and at the same time, press the Reset button
until you hear the "Restoring factory settings.
This will take about 5 minutes." voice message.
The robot will then be restored to factory settings.
Routine Maintenance
D
Note:
The frequency of replacement may vary with the
actual situation. If abnormal wear occurs, replace the
parts immediately.
Main Brushes
D1
* Clean every 2 weeks and replace every 6-12 months.
D1-1—Main Brush Cover
D1-2—Main Brush Cover Latches
D1-3—Main Brushes
D1-4—Main Brush Bearing
D1-5—Turn over the robot and press the
two latches inwards to remove the
main brush cover.
D1-6—Lift the main brushes and pull them
out, remove bearings and remove
any entangled hair or dirt at both
ends of the main brushes and
bearings.
D1-7—Reinstall the main brush bearings.
And then, reinstall the main brushes
and make sure the color of the main
brush, main brush bearing and the
arrow on the robot match.
D1-8— Reinstall the main brush cover. Make
sure its four teeth are fully seated in
the slots, and press the main brush
cover until you hear it lock with a click.
Notes:
• To securely install the main brush cover, make sure to
press both of the main brush cover latches in place.
• It is recommended to wipe the main brushes with a
wet cloth. If the main brushes are wet, air-dry them
away from direct sunlight.
• Do not use corrosive cleaning fluid or disinfectant to
clean the main brushes.
Side Brush
D2
* Clean monthly and replace every 3-6 months.
D2-1—Turn over the robot, unscrew the
side brush, then remove and clean it.
D2-2—Align the central groove with the raised
position on the robot, then tighten
the screw to reinstall the side brush.
Omnidirectional Wheel
D3
* Clean as required.
D3-1—Use a tool, such as a small screwdriver,
to pry out the axle and take out the wheel.
Note:
The omnidirectional wheel bracket cannot be removed.
D3-2—Rinse the wheel and the axle with
water to remove any hair and dirt.
Air-dry, reinstall, and press the wheel
and axle back in place.
Main Wheels
D4
* Clean as required.
Clean the main wheels with a soft, dry cloth.
Dustbin
D5
* Clean as required.
D5-1—Remove the magnetic top cover of
the robot and press the dustbin latch
to take out the dustbin.
010
D5-2—Remove the washable filter and
empty the dustbin.
D5-3—Fill the dustbin with clean water and
reinstall the washable filter. Gently
shake the dustbin, and then pour out
the dirty water.
Note:
To prevent blockage, only use clean water without
any cleaning liquid.
D5-4—Allow at least 24 hours for the dustbin
and washable filter to dry thoroughly
before reinstalling them.
Washable Filter
D6
* Clean every 2 weeks and replace every 6-12 months.
D6-1—Remove the filter.
D6-2—Rinse the filter repeatedly and tap it
to remove as much dirt as possible.
Note:
Do not touch the surface of the filter with hands,
brushes, or hard objects to avoid potential damage.
D6-3—Allow at least 24 hours for the filter to
dry thoroughly before reinstalling it.
Mop Cloths
D7
* Clean as required and replace every 1-3 months.
D7-1—Remove the mop cloths from mop
cloth mounts. Clean the mop cloths
and air-dry them.
Note:
A dirty mop cloth will affect the mopping
performance. Clean it before use.
D7-2—Stick the mop cloths on the mounts
flat in place.
