Product Overview
A
Robot (Top View)
A1
—Power/Clean
• Press and hold to turn the robot
on or off
• Press to start cleaning
—Power Indicator Light
• White: Battery level ≥ 15%
• Red: Battery level < 15%
• Breathing: Charging or starting up
• Flashing red: Error
• Breathing blue: Remote viewing
• Flashing blue slowly: Waiting for
WiFi connection
• Flashing blue quickly: Connecting
• Steady blue: Voice assistant
working/WiFi connected
—Dock
• Robot not on dock: Press to start
docking/Press and hold to start
spot cleaning
• Robot on dock: Press to start
emptying/Press and hold to wash
the mop cloths
Note:
Press any button to pause a running robot.
A1-1—Microphones
A1-2—Vertical Bumper
A1-3—LiDAR Sensor
A1-4—LED Fill Light
A1-5—Dock Locator
A1-6—Reactive AI Obstacle Recognition
Sensor
A1-7—Bumper
A1-8—Wall Sensor
Robot (Bottom View)
A2
A2-1—Cliff Sensors
A2-2—Carpet Sensor
A2-3—Side Brush
A2-4—Main Brush Cover
A2-5—Omnidirectional Wheel
A2-6—Main Brushes
A2-7—Main Brush Cover Latches
A2-8—Main Wheels
A2-9—Mop Cloths
Robot (Top Cover Removed)
A3
A3-1—Magnetic Top Cover
A3-2—Suction Inlet
A3-3—Automatic Lift and Rotate Mop
Modules
A3-4—Reset Button
A3-5—Dustbin
A3-6—Charging Contacts
A3-7—Air Outlets
A3-8—Communication Sensor
A3-9—Self-Filling Port
A3-10—Positioning Button
Mop Cloth Mount
A4
A4-1—Hook and Loop Pads
A4-2—Mop Axle
Note:
Secure the mop cloths flat in place.
006
Mop Cloth
A5
Dustbin
A6
A6-1—Dustbin Latch
A6-2—Suction Inlet
A6-3—Air Inlet
A6-4—Washable Filter
A6-5—Filter Latch
Dock Base
A7
Power Cord
A8
Disposable Dust Bag
A9
Empty Wash Fill Dock
A10
A10-1—Water Tank Handle
A10-2—Water Tank Latch
A10-3—Dust Container Cover
A10-4—Charging Contacts
A10-5—Robot Refill Port
A10-6—Drain Port
A10-7—Cleaning Tray Filter
A10-8—Dock Base
A10-9—Dirty Water Tank
A10-10—Clean Water Tank
A10-11—Status Indicator Light
• Breathing: Emptying/Mop washing
• Red: Dock error
• Off: Powered off/Charging
