Scale factors
The following scale factors are used when using
DRANFLEX 3003XLB sensors with Dranetz
instruments.
SENSOR
DRANFLEX 3003XLB 3000 A
DRANFLEX 6003XLB 6000 A
Measuring low level currents
When measuring Neutral currents or levels at the low
end of the sensor ratings you can increase the accuracy
and sensitivity by placing the flexible sensor end around
the conductor(s) twice. When utilizing the sensor in this
manner, you must also divide the scale factors by two
(2). For example: 300 A Scale Factor of 200 would
translate to a Scale Factor of 100.
RANGE
SCALE FACTORS
30 A
300 A
3000 A
60 A
600 A
6000 A
20
200
2000
40
400
4000
