Fig. 9: Reinstall the front housing onto SSAG. Don't forget the orange cosmetic ring!
6. To install SSAG into your telescope's standard finderscope dovetail
base, simply insert the small bracket into the base and tighten the
thumbscrew on the base to secure it in place.
Now that you have installed SSAG, you'll need to connect its AUX port
to one of the AUX ports on your telescope mount. Use the supplied AUX
cable (Fig. 10). If you do not have an available AUX port on your mount,
consider purchasing an optional Celestron AUX Port Splitter.
AUX port (on SSAG)
AUX cable
AUX port (on mount)
Fig. 10: Use the supplied AUX cable to connect SSAG's AUX port to the mount's AUX
port.
WARNING: DO NOT PLUG STARSENSE AUTOGUIDER INTO YOUR
MOUNT'S AUTOGUIDER PORT!
Always connect StarSense Autoguider
to one of your mount's AUX ports. Connecting it to the Autoguider port
could damage StarSense Autoguider.
3. Controlling Your StarSense Autoguider
There are several ways to control your StarSense Autoguider:
NexStar+ Hand Control
To use SSAG with the NexStar+ hand control that came with your
Celestron mount, you will likely need to update the hand control's
firmware. You'll need firmware version 5.35.XXXX or greater. To
check your firmware version number, press the MENU button. Use
the SCROLL and ENTER buttons to navigate to Utilities>Version.
Use the Celestron Firmware Manager (CFM) software to update
the firmware if needed. You'll find the latest version of CFM here:
celestron.com/pages/drivers-and-software
You'll need a USB cable (Type-A to Mini-B) to connect the hand control to
your PC. Refer to section 9 of this manual (page 10) for more information.
CPWI Telescope Control Software for PC
You can control your telescope and StarSense Autoguider with our
free Celestron CPWI software. To download the latest version, visit:
celestron.com/pages/celestronpwi-telescope-control-software
You'll need CPWI version 2.5.0 or greater. Install the software and open
CPWI. Select "Start" if the opening window appears. Then, click on the
"Connection" icon in the upper left corner of the screen. If you are using a
wired connection to your Celestron mount (i.e., through the hand control or
the mount itself), select "USB." If you are using the SkyPortal WiFi Module,
select "WiFi." CPWI should find and connect to the autoguider. Once
connected, the SSAG icon will appear in the selection menu on the left side
of the screen. Select the icon to display the StarSense Autoguider menu
(Fig. 11).
Fig. 11: When you connect your Celestron mount to your PC and launch CPWI,
you should see the StarSense AG menu among the icons on the left side
of the screen.
SkyPortal App for iOS and Android
If you use the Celestron SkyPortal WiFi Module or have a Celestron
mount with built-in WiFi (e.g., NexStar Evolution), you can use the
SkyPortal app to control your SSAG. Please refer to the Support &
Downloads section on the StarSense Autoguider page at celestron.com
for more information.
ENGLISH | 3
