Using devolo Cockpit
b
devolo Home Network App (see Chapter 3.5
Installation of devolo software),
Only using the PLC button (see Chapter 2.3
b
Pairing and 3.4.2 Addition – Expanding an
existing network
devolo Magic adapter)
Using the web interface, in the Powerline
b
menu; as described below:
Pairing – Using on-screen button
Click Start pairing to start the pairing opera-
1
tion. This may take some time.
As soon as the new devolo Magic adapter is
2
integrated into your existing network, it
appears in a list of available and established
connections (see Chapter Connections).
Pairing – Using custom password
You can also assign your network a custom PLC
password you pick yourself. Enter this password for
each devolo Magic adapter in the Powerline
password field and confirm your entry with OK.
Note that the custom password is not assigned
to the whole PLC network automatically. In-
stead, you must assign it separately to each of
your devolo Magic adapters.
or the
by adding another
Powerline domain name
The Powerline domain name determines the name
of your PLC network.
Unpairing – Resetting or removing an adapter
from a network
To remove a devolo Magic adapter from your
1
devolo Magic network, click Leave Powerline
network.
Wait until the PLC LED flashes white and then
2
disconnect the devolo Magic adapter from the
mains supply.
4.3.2 Compatibility mode
Using as VDSL connection may negatively impact
the performance of the bandwidth connection by
crosstalk of the signal.
In order to mitigate any potential negative effects
the device provides the following options:
devolo Magic 2 LAN triple
Configuration 28
